Logistics matrix high-speed linear sorting equipment
Wireless power supply technology, low noise, efficiency up to 8000pieces /H, maintenance-free, high stability, easy to disassemble.
- LIJI
- Shanghai.China
- 90days
- 90days
- Information
Conveying and driving mode | Three-phase AC asynchronous motor | Conveying transmission mode | Permanent magnet linear motor |
Sorting drive mode | 48V electric servo drum | The effective width of the equipment | 1060mm |
Equipment thickness | 800 mm | The longest length of the equipment | 180 m |
cart distance | 200mm | Supply method | Wireless power supply |
cart driving power | 400W | Delivery speed | 1.2-3 m/s |
Sorting speed | 1.5 m/s~2.5m/s | Minimum spacing of goods | 300 mm |
Delivery speed 1.5m/s | ≥5500 pieces/hour | Delivery speed 2m/s | ≥7500 pieces/hour |
Delivery speed 2.5m/s | ≥9000 pieces/hour | Delivery speed 3m/s | ≥10,500 pieces/hour |
Delivery speed 1.5m/s | ≤70 dB | Delivery speed 2m/s | ≤72 dB |
Delivery speed 2.5m/s | ≤76 dB | Delivery speed 3m/s | ≤78 dB |
What are the advantages of this equipment？
low noise, efficiency up , maintenance-free, high stability, easy to disassemble.
Which fields are they used in？
Express/express, e-commerce, home appliances, home textiles, airport transportation equipment.
What are the disadvantages of this device？
High cost, durable, at least 8-10 years
What is the minimum temperature that this equipment can withstand？
Minus 25 degrees
How much sorting efficiency can be achieved？
99.99%
What is the maximum and minimum size of the type of goods to be sorted？
Minimum: L=50mm W=50mm H=10mm ，Maximum L= 1200mm W= 1000mm H=1000mm
Are you the source manufacturer or the trader？
the source manufacturer
